SMARTRE-FLEX

SMART repair spray booth

Standard car size retractable SMART repair booth with powerful extraction and built-in workstation that folds away to just 1.88 metres, freeing up valuable indoor workshop floorspace.

Fixed price

£12,250 ex VAT

• Finance available from £429.98/mo on a 3 year agreement*

Key features

›Retracts from 6.83m to 1.88m, freeing around 72% of the floor
›Spark proof extraction at 1.80m3/s, built to pass LEV testing
›Built in workstation with paint mixing bench
›Standard car size, drive in through the zip up front
›Flame retardant clear sheeting for natural light and colour matching
›Free standing, two stage dry filtration

Get a quote → Call 01753 59 59 55

Suitable for

For bodyshops and SMART repair centres carrying out repairs, panel painting, priming and alloy wheel refurbishment on cars.

Industries

Automotive

Overview

Pass your LEV test and keep your floor space. The SMARTRE-FLEX gives SMART repairs, panel painting, priming and alloy wheel work a dedicated bay with spark proof extraction at 1.80m3/s, a personnel door and a built in workstation with paint mixing bench. Zip open the front, drive the car in, and the semi clear flame retardant sheeting floods the bay with natural light for colour work. When spraying is finished, the booth retracts from 6.83 metres to 1.88 metres and the floor goes back to work.

Recommended uses

SMART repairs, panel painting, priming and alloy wheel refurbishment on cars in bodyshops, SMART repair centres and dealerships. The zip up front opening gives easy vehicle access; the replaceable air inlet filter panel gives an enclosed clean air environment when closed.

4.1m W x 2.4m H x 6.83m L
Retracts back to 1.88m
Work area of 3 modules

Exhaust fan: 1 x 0.75kW 3 phase belt driven axial fan with extraction rate of 1.80m3/s. Spark proof fan and motor
Exhaust filter: filtration by way of 2 x green and white extract filter media at 1000mm high mounted in the exhaust chamber
Exhaust ducting: fan supplied with a 500mm dia duct connector
The system is free standing and only requires ducting penetration through an outside wall to provide ventilation to the work area

Work area constructed from 3 modules of powder coated steel tube framework with semi clear reinforced flame retardant PVC sheeting attached to the inside (530g/m2, 0.45mm, BS7837:1996)
Zip up front opening for easy access
Replaceable air inlet filter panel in the centre section providing an enclosed clean air environment
Plenum body: 1.0mm galvanised sheet metal of modular design, turret punched, pre-folded and ready for easy bolt together assembly, c/w personnel door and workstation paint mixing bench

The system should be installed in accordance with HSG140 paragraphs 222 and 223
The Hazardous Zone 2 area extends to a minimum of 2m either side and front of the extended work area
Supplied with a documented maintenance programme; failure to comply may cause warranties to become null and void

Standard car size: 6.83m L x 4.1m W x 2.4m H
Infrared drying lamps

At a glance

Price £12,250

Category SMART repair booths

Lead time 5 to 6 weeks

Get a quote

Frequently asked questions

The booth is built for it: a spark proof fan extracting at 1.80m3/s through two stage filter media, installed to HSG140 paragraphs 222 and 223, with a documented maintenance programme to keep it performing between tests.

The work area is 6.83m long, 4.1m wide and 2.4m high, sized for standard cars. For vans and light commercial vehicles, choose the SMARTRE-FLEX COMMERCIAL.

1.88 metres. The three module work area folds back against the plenum, returning almost 5 metres of bay length to the workshop.

£12,250 ex VAT with finance available. Lead time is 5 to 6 weeks, with payment at 50% on order, 30% prior to dispatch and 20% on delivery.

A qualified electrician for all electrical supply and connections (excluded from the price), and ducting penetration through an outside wall for the 500mm exhaust.
